Cantilever Shafts / stepped / double-sided female thread / flat spanner

Cantilever Shafts / stepped / double-sided female thread / flat spanner
View the FAQ (7)

MISUMI

MISUMI

Data sheet

Unit еxample related to this product
Pallet centering mechanism
Search for оther еxamples

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Cantilever Shaft - Screw Mount, Tapped End, Standard Dimensional Drawing
Dimensions of Wrench Flats when Y ≥ 17
Type[M] Material[S] Surface treatment
FXHBEN 1.1191 Equiv.Black Oxide
PFXHBElectroless Nickel Plating
SFXHBEN 1.4301 Equiv.—
PHFXHBEN 1.7220 Equiv.
Hardness 35 to 40 HRC		Electroless Nickel Plating

Specification Table

Part Number—Y—F—MA
FXHB20
FXJB12
SF−PFXJB17		—
—
—		17
24
30		—
—
—		F25
F18
F50		—
—
—		MA10
MA6
MA8
Part NumberDg61 mm IncrementsMA (Coarse)
Selection		M
(Coarse)		HW
TypeNo.YF
FXHB

PFXHB

SFXHB

PHFXHB		 6 6− 0.004
− 0.012		2 to 60 5 to 100 3        M 310 8
6 A1412
 8 8− 0.005
− 0.014		  4       M 41210
8 A1614
1010  4 5 6     M 61513
10 A2017
1212− 0.006
− 0.017		10 to 150   5 6 8    M 81714
13131815
1515    6 810   M102017
16162118
17172320
1818
2020− 0.007
− 0.020		4 to 75    6 81012  M122624
20 AM 8
2222M162826
22 AM12
2525     8101216 M163127
25 AM12
3030     810121620M203632
30 AM16

DMt
6M 311
8M 412.5
10M 614
12·13M 817
15M1020
16
17
18
20M1225
22M16
2531
30M2037
Specify dimensions Y and F not to make the dimension "t" less than the values in the table above.

Alterations

Part Number—Y—F—MA—(YKC·WSC·APC)
FXHB25—50—F32—MA10—YKC − APC
AlterationsY Dimension ToleranceFour Wrench FlatsAdds a Pilot
Cantilever Shaft - Screw Mount, Tapped End, Standard Alteration 1Cantilever Shaft - Screw Mount, Tapped End, Standard Alteration 2Cantilever Shaft - Screw Mount, Tapped End, Standard Alteration 3
CodeYKCWSCAPC
Spec.Changes Y dimension tolerance to ± 0.05.
[!] Applicable to all types
Ordering Code YKC		Changes from two wrench flats to four wrench flats.
[!] Applicable to Standard and Stepped Types
Ordering Code WSC		Adds a pilot to the shaft seat.
[!] Applicable to all types
Ordering Code APC
DMAPCg6
6M 36
8M 48
10M 610
12M 812
1313
15M1015
1616
1717
1818
DMAPCg6
20M1220
2222
25M1625
25 AM12
30M2030
30 AM16

Part Number:

    3D preview is not available, because the part number has not yet been determined.

  • In order to open the 3D preview, the part number must be fixed.
Loading...

Plug-in is required for 3D Preview

CAD Download

Data to be displayed
30
45
60
  1. 1
  2. 2
  3. Next >>
Part Number
FXHB6-[2-60/1]-F[5-100/1]-MA3
FXHB6A-[2-60/1]-F[5-100/1]-MA3
FXHB8-[2-60/1]-F[5-100/1]-MA4
FXHB8A-[2-60/1]-F[5-100/1]-MA4
FXHB10-[2-60/1]-F[5-100/1]-MA[4,​5,​6]
FXHB10A-[2-60/1]-F[5-100/1]-MA[4,​5,​6]
FXHB12-[2-60/1]-F[10-150/1]-MA[5,​6,​8]
FXHB13-[2-60/1]-F[10-150/1]-MA[5,​6,​8]
FXHB15-[2-60/1]-F[10-150/1]-MA[6,​8,​10]
FXHB16-[2-60/1]-F[10-150/1]-MA[6,​8,​10]
FXHB17-[2-60/1]-F[10-150/1]-MA[6,​8,​10]
FXHB18-[2-60/1]-F[10-150/1]-MA[6,​8,​10]
FXHB20-[4-75/1]-F[10-150/1]-MA[6,​8,​10,​12]
FXHB20A-[4-75/1]-F[10-150/1]-MA[6,​8,​10,​12]
FXHB22-[4-75/1]-F[10-150/1]-MA[6,​8,​10,​12]
FXHB22A-[4-75/1]-F[10-150/1]-MA[6,​8,​10,​12]
FXHB25-[4-75/1]-F[10-150/1]-MA[8,​10,​12,​16]
FXHB25A-[4-75/1]-F[10-150/1]-MA[8,​10,​12,​16]
FXHB30-[4-75/1]-F[10-150/1]-MA[8,​10,​12,​16,​20]
FXHB30A-[4-75/1]-F[10-150/1]-MA[8,​10,​12,​16,​20]
PFXHB6-[2-60/1]-F[5-100/1]-MA3
PFXHB6A-[2-60/1]-F[5-100/1]-MA3
PFXHB8-[2-60/1]-F[5-100/1]-MA4
PFXHB8A-[2-60/1]-F[5-100/1]-MA4
PFXHB10-[2-60/1]-F[5-100/1]-MA[4,​5,​6]
PFXHB10A-[2-60/1]-F[5-100/1]-MA[4,​5,​6]
PFXHB12-[2-60/1]-F[10-150/1]-MA[5,​6,​8]
PFXHB13-[2-60/1]-F[10-150/1]-MA[5,​6,​8]
PFXHB15-[2-60/1]-F[10-150/1]-MA[6,​8,​10]
PFXHB16-[2-60/1]-F[10-150/1]-MA[6,​8,​10]
PFXHB17-[2-60/1]-F[10-150/1]-MA[6,​8,​10]
PFXHB18-[2-60/1]-F[10-150/1]-MA[6,​8,​10]
PFXHB20-[4-75/1]-F[10-150/1]-MA[6,​8,​10,​12]
PFXHB20A-[4-75/1]-F[10-150/1]-MA[6,​8,​10,​12]
PFXHB22-[4-75/1]-F[10-150/1]-MA[6,​8,​10,​12]
PFXHB22A-[4-75/1]-F[10-150/1]-MA[6,​8,​10,​12]
PFXHB25-[4-75/1]-F[10-150/1]-MA[8,​10,​12,​16]
PFXHB25A-[4-75/1]-F[10-150/1]-MA[8,​10,​12,​16]
PFXHB30-[4-75/1]-F[10-150/1]-MA[8,​10,​12,​16,​20]
PFXHB30A-[4-75/1]-F[10-150/1]-MA[8,​10,​12,​16,​20]
PHFXHB6-[2-60/1]-F[5-100/1]-MA3
PHFXHB6A-[2-60/1]-F[5-100/1]-MA3
PHFXHB8-[2-60/1]-F[5-100/1]-MA4
PHFXHB8A-[2-60/1]-F[5-100/1]-MA4
PHFXHB10-[2-60/1]-F[5-100/1]-MA[4,​5,​6]
PHFXHB10A-[2-60/1]-F[5-100/1]-MA[4,​5,​6]
PHFXHB12-[2-60/1]-F[10-150/1]-MA[5,​6,​8]
PHFXHB13-[2-60/1]-F[10-150/1]-MA[5,​6,​8]
PHFXHB15-[2-60/1]-F[10-150/1]-MA[6,​8,​10]
PHFXHB16-[2-60/1]-F[10-150/1]-MA[6,​8,​10]
PHFXHB17-[2-60/1]-F[10-150/1]-MA[6,​8,​10]
PHFXHB18-[2-60/1]-F[10-150/1]-MA[6,​8,​10]
PHFXHB20-[4-75/1]-F[10-150/1]-MA[6,​8,​10,​12]
PHFXHB20A-[4-75/1]-F[10-150/1]-MA[6,​8,​10,​12]
PHFXHB22-[4-75/1]-F[10-150/1]-MA[6,​8,​10,​12]
PHFXHB22A-[4-75/1]-F[10-150/1]-MA[6,​8,​10,​12]
PHFXHB25-[4-75/1]-F[10-150/1]-MA[8,​10,​12,​16]
PHFXHB25A-[4-75/1]-F[10-150/1]-MA[8,​10,​12,​16]
PHFXHB30-[4-75/1]-F[10-150/1]-MA[8,​10,​12,​16,​20]
PHFXHB30A-[4-75/1]-F[10-150/1]-MA[8,​10,​12,​16,​20]
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
RoHSShaft Diameter
(mm) 		Material Surface Treatment Hardness Material M (Coarse) H Dimension
(mm) 		F
(mm) 		Thread Dia. Selection [MA] Y
(mm)

-

1 4 Days 106SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.3105 ～ 10032 ～ 60

-

1 4 Days 106SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.3145 ～ 10032 ～ 60

-

1 4 Days 108SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.4125 ～ 10042 ～ 60

-

1 4 Days 108SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.4165 ～ 10042 ～ 60

-

1 4 Days 1010SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.6155 ～ 1004 ～ 62 ～ 60

-

1 4 Days 1010SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.6205 ～ 1004 ～ 62 ～ 60

-

1 4 Days 1012SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.81710 ～ 1505 ～ 82 ～ 60

-

1 4 Days 1013SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.81810 ～ 1505 ～ 82 ～ 60

-

1 4 Days 1015SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.102010 ～ 1506 ～ 102 ～ 60

-

1 4 Days 1016SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.102110 ～ 1506 ～ 102 ～ 60

-

1 4 Days 1017SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.102310 ～ 1506 ～ 102 ～ 60

-

1 4 Days 1018SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.102310 ～ 1506 ～ 102 ～ 60

-

1 4 Days 1020SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.122610 ～ 1506 ～ 124 ～ 75

-

1 4 Days 1020SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.82610 ～ 1506 ～ 124 ～ 75

-

1 4 Days 1022SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.162810 ～ 1506 ～ 124 ～ 75

-

1 4 Days 1022SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.122810 ～ 1506 ～ 124 ～ 75

-

1 4 Days 1025SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.163110 ～ 1508 ～ 164 ～ 75

-

1 4 Days 1025SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.123110 ～ 1508 ～ 164 ～ 75

-

1 4 Days 1030SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.203610 ～ 1508 ～ 204 ～ 75

-

1 4 Days 1030SteelBlack OxideHardness Not Spec-designedEN 1.1191 Equiv.163610 ～ 1508 ～ 204 ～ 75

-

1 4 Days 106SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.3105 ～ 10032 ～ 60

-

1 4 Days 106SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.3145 ～ 10032 ～ 60

-

1 4 Days 108SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.4125 ～ 10042 ～ 60

-

1 4 Days 108SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.4165 ～ 10042 ～ 60

-

1 4 Days 1010SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.6155 ～ 1004 ～ 62 ～ 60

-

1 4 Days 1010SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.6205 ～ 1004 ～ 62 ～ 60

-

1 4 Days 1012SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.81710 ～ 1505 ～ 82 ～ 60

-

1 4 Days 1013SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.81810 ～ 1505 ～ 82 ～ 60

-

1 4 Days 1015SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.102010 ～ 1506 ～ 102 ～ 60

-

1 4 Days 1016SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.102110 ～ 1506 ～ 102 ～ 60

-

1 4 Days 1017SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.102310 ～ 1506 ～ 102 ～ 60

-

1 4 Days 1018SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.102310 ～ 1506 ～ 102 ～ 60

-

1 4 Days 1020SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.122610 ～ 1506 ～ 124 ～ 75

-

1 4 Days 1020SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.82610 ～ 1506 ～ 124 ～ 75

-

1 4 Days 1022SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.162810 ～ 1506 ～ 124 ～ 75

-

1 4 Days 1022SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.122810 ～ 1506 ～ 124 ～ 75

-

1 4 Days 1025SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.163110 ～ 1508 ～ 164 ～ 75

-

1 4 Days 1025SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.123110 ～ 1508 ～ 164 ～ 75

-

1 4 Days 1030SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.203610 ～ 1508 ～ 204 ～ 75

-

1 4 Days 1030SteelElectroless Nickel PlatingHardness Not Spec-designedEN 1.1191 Equiv.163610 ～ 1508 ～ 204 ～ 75

-

1 9 Days 106SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.3105 ～ 10032 ～ 60

-

1 9 Days 106SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.3145 ～ 10032 ～ 60

-

1 9 Days 108SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.4125 ～ 10042 ～ 60

-

1 9 Days 108SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.4165 ～ 10042 ～ 60

-

1 9 Days 1010SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.6155 ～ 1004 ～ 62 ～ 60

-

1 9 Days 1010SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.6205 ～ 1004 ～ 62 ～ 60

-

1 9 Days 1012SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.81710 ～ 1505 ～ 82 ～ 60

-

1 9 Days 1013SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.81810 ～ 1505 ～ 82 ～ 60

-

1 9 Days 1015SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.102010 ～ 1506 ～ 102 ～ 60

-

1 9 Days 1016SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.102110 ～ 1506 ～ 102 ～ 60

-

1 9 Days 1017SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.102310 ～ 1506 ～ 102 ～ 60

-

1 9 Days 1018SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.102310 ～ 1506 ～ 102 ～ 60

-

1 7 Days 1020SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.122610 ～ 1506 ～ 124 ～ 75

-

1 9 Days 1020SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.82810 ～ 1506 ～ 124 ～ 75

-

1 7 Days 1022SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.162810 ～ 1506 ～ 124 ～ 75

-

1 9 Days 1022SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.122610 ～ 1506 ～ 124 ～ 75

-

1 7 Days 1025SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.163110 ～ 1508 ～ 164 ～ 75

-

1 7 Days 1025SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.123110 ～ 1508 ～ 164 ～ 75

-

1 7 Days 1030SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.203610 ～ 1508 ～ 204 ～ 75

-

1 7 Days 1030SteelElectroless Nickel PlatingHardness Spec-designedEN 1.7220 Equiv.163610 ～ 1508 ～ 204 ～ 75

Loading...

  1. 1
  2. 2
  3. Next >>

App. Example

General Information - Cantilever Shafts

Cantilever bins with retaining ring groove - cantilever pin with external thread - cantilever pin with thread - cantilever pin with collar - cantilever pin with shoulder - cantilever pin with female thread - cantilever pin with flange - cantilever pin with flange and collar



Selection details of cantilever shafts/cantilever bolts

- Material: stainless steel, steel, tempered steel

- Coatings: untreated, burnished, nickel-plated

- Fastening: retaining ring, internal thread, external thread, centring collar with internal thread

- ISO tolerance: g6

- Thread: M3 to M20

- Straightness: up to 0.02 mm

- Roundness: up to 0.02 mm

- Shaft diameter: 3 to 50 mm

-Length: 3 to 150 mm


Description/Basics

They are basically used to support rotary rolling bearings. The support position can be precisely determined by its configurability. The different mounting variants offer a compact and space-saving option for many applications, e.g., to accommodate ball bearings.
Cantilever shafts with collar or shoulder are well suited to determine a support position. The collar serves as a contact surface for the bearing inner wheel. Since the collar of the cantilever shaft can be configured, individual adaptation is simple. The variant [YKC] offers the option of a particularly precise axle bolt with collar, with a length tolerance of +/- 0.05 mm. Due to this property, an additional washers can be omitted with this cantilever shaft.
The cantilever shafts are also available with double collars or double offset. These are suitable for idler pulleys with a small diameter, since the reduced additional shoulder can prevent grinding of the idler pulley.
Cantilever shafts with retaining ring groove (groove) are the most commonly used bearing bolts, because the retaining rings allows for easy assembly and disassembly. The cantilever shafts including the retaining ring can be delivered with the [SET] option. We also offer threaded cantilever shafts that can be selected with external threads or internal threads.
As a special form, our product range offers cantilever shafts with flanges. Due to the large contact surface, higher forces can be absorbed and distributed more evenly compared to conventional cantilever shafts. If you want to attach ball bearings that also have to withstand axial forces, for example, the cantilever shaft with flange offers a good solution. Due to its versatility, the cantilever shaft with flange can be used for a wide variety of design solutions.
Our product range includes various drives for assembly. From the typical hexagon to spanner flat, to additional cross holes with threads that can be used for example for a tension application for clamping devices.

The field of application of cantilever shafts in mechanical engineering is fundamentally very large. They are utilised in synchronous drives, chain transmission or in various tasks in device construction
Bearing pins can be used in combination with ball bearings or plain bearing bushings. Among other things, you can select roller idlers (with rolling bearings), idler pulleys or timing pulleys. As an alternative for limited installation space, we offer cam rollers, which come assembled and ready to install consisting of cantilever shafts and rolling bearings.
Bearing pins are also often used in conjunction with links to ensure different movement sequences.
For high loads, we offer the cantilever shafts made of heat-treated steel, which are produced to be wear-resistant and durable with a hardness of up to 40HRC.

Our product range also offers suitable screws and nuts for fastening cantilever shafts.



Application Examples - Cantilever Shafts

Application example - cantilever pin with idler pulley - cantilever pin with female thread - shaft for idler pulley - bolt for idler pulley - cantilever bolt with thread

Application example: deflection roller
(1) Cantilever shaft, (2) Idler pulley, (3) Spacer washer, (4) Mounting angle, (5) Screw, (6) Mounting plate

Application example - cantilever pin with chain idler - cantilever pin with centring collar - cantilever pin double offset - cantilever pin with double collar - cantilever pin with female thread

Application example: chain idlers
(1) Cantilever shafts, (2) Chain idlers, (3) Spacer washer, (4) Screw

Application example - cantilever pin with clamping device - cantilever pin for clamping device - cantilever pin with cross hole and thread - cantilever pin with male thread - cantilever pin with thread - roller tensioner with adjusting screw

Application example: idler pulley
(1) Cantilever shaft, (2) Locknut, (3) Washer, (4) Idler pulley, (5) Threaded stopper block, (6) Adjusting screw

Application example - cantilever pin with plain bearing bushing - cantilever pin with retaining ring - cantilever pin with male thread - cantilever pin with articulated arm - cantilever pin with thrust washer - cantilever pin with thread

Application example: link with plain bearing bushing
(1) Cantilever shaft, (2) Retaining ring, (3) Links, (4) Plain bearing bushing, (5) Thrust washer



Industrial Applications

3D printer industry
Automotive industry
Pharmaceutical industry
Packaging industry


Basic information

Shaft Retaining Method Tapered (Screw) Bearing Retaining Method Tapered (Screw) Shoulder Shape Wrench Flats

Configure

Clear all

80Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.
The part number is completed.

Basic Attributes

  • Shaft Diameter(mm)

    • 6
    • 8
    • 10
    • 12
    • 13
    • 15
    • 16
    • 17
    • 18
    • 20
    • 22
    • 25
    • 30

    Clear

  • Material

    • Steel
    • Stainless Steel

    Clear

  • Surface Treatment

    • Not Provided
    • Black Oxide
    • Electroless Nickel Plating

    Clear

  • Hardness

    • Hardness Spec-designed
    • Hardness Not Spec-designed

    Clear

  • Material

    • EN 1.1191 Equiv.
    • EN 1.4301 Equiv.
    • EN 1.7220 Equiv.

    Clear

  • M (Coarse)

    • 3
    • 4
    • 6
    • 8
    • 10
    • 12
    • 16
    • 20

    Clear

  • H Dimension(mm)

    • 10
    • 12
    • 14
    • 15
    • 16
    • 17
    • 18
    • 20
    • 21
    • 23
    • 26
    • 28
    • 31
    • 36

    Clear

  • F(mm)

     [5-150/1mm Unit(s)]

    Clear

  • Thread Dia. Selection [MA]

    • 3
    • 4
    • 5
    • 6
    • 8
    • 10
    • 12
    • 16
    • 20

    Clear

  • Y(mm)

     [2-75/1mm Unit(s)]

    Clear

  • Type

    • FXHB
    • PFXHB
    • PHFXHB
    • SFXHB

    Clear

  • Filter by CAD data type

    • 2D
    • 3D

    Clear

Filter by standard shipping days

    • All
    • 3 Days or Less
    • 4 Days or Less
    • 7 Days or Less
    • 9 Days or Less

    Reset

Optional Attributes

Frequently Asked Questions (FAQ)

Question:

Do you have long axle bolts?
Answer:

We offer axle bolts in a configurable length of approx. 150 mm. If this length is not sufficient, a rotary axle may serve as an alternative depending on the design.
Question:

Do you have hollow axle bolts?
Answer:

Currently, we do not offer hollow axle bolts in our product line. However, MISUMI offers hollow rotary axles. These can be configured in a similar way and represent a possible alternative depending on the application.
Question:

What is the roundness of the axle bolts?
Answer:

Depending on the cantilever shaft, the roundness is up to 0.02 mm. It is recommended to refer to the values specified in the corresponding technical drawing and the specifications of the axle bolt.
Question:

How straight are axle bolts aligned?
Answer:

Our axle bolts are manufactured to a precise straightness of approx. 0.02 mm. The assembly side of the MISUMI axle bolts is finer to allow for a straight fit and exact alignment. Refer to technical drawing or specifications for details.
Question:

Are axle bolts with flange suitable for tension rollers?
Answer:

Flange cantilever shafts can also be used in idler pulley applications. If a cantilever shaft with collar can be used, an additional spacer sleeve can be omitted. The collar of the flange cantilever shaft is configurable and can be individually adjusted to the bearing position.
Question:

Do you have stainless axle bolts?
Answer:

MISUMI offers stainless steel cantilever shafts. In addition, our steel cantilever shafts are available with an optional surface treatment to protect them from corrosion and environmental conditions. Our cantilever shafts are available in both burnished and nickel-plated options.
Question:

Do you have axle bolts made of alloy quenched and tempered (Q & T) steel?
Answer:

In the MISUMI online shop, you will find a large number of cantilever shafts made of tempered steel. These can be additionally protected against corrosion with burnished or nickel-plated finishes.

Show more FAQ Close

Complementary Products

MISUMI Unit еxample related to this product

Search for оther еxamples

back next

Tech Support

Technical Support
Tel：+49 69 668173-0 / FAX：+49 69 668173-360
Technical Inquiry

Payment Method

  • Payment on account
  • Pre Payment
  • PayPal

On-Demand Manufacturing

Change View

Certificates

  • ISO-9001
  • ISO-14001
  • AEO Certification
  • RoHS
  • REACH

MISUMI worldwide

Social Media

Legal notice

Copyright © MISUMI Corporation All Rights Reserved.
