Caution / Warning / Danger Stickers
Click on this image to zoom in.
Click on this image to zoom in.
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Drawing / Specifications
- 3D Preview 3D preview is available after complete configuration
- Part Numbers
- Catalog
■Japanese
Portrait Type
LH□S
LH□M
LH□L
■Japanese
Landscape Type
LW□S
LW□M
LW□L
■Chinese
Landscape Type
CHW
CHC
CHD
■English
Portrait Type
PE□
Operating Ambient Temperature
－20 to 80°C
■Japanese
Portrait Type
LHWS LHWM LHWL
Portrait Type
LHCS LHCM LHCL
Portrait Type
LHDS LHDM
Landscape Type LWWS LWWM LWWL
Landscape Type LWCS LWCM LWCL
Landscape Type LWDS LWDM LWDL
■English
Portrait Type
PEW
Portrait Type
PEC
Portrait Type
PED
■Chinese
Landscape Type CHW
CHC
CHC
CHD
Specification Table
| Part Number |
| LHWS−03 PEC−02 |
| Part Number | A | B | W | E | F | G | H | ||||
| Type | Warning | Caution | Danger | Nominal | |||||||
| Japanese Portrait Type | LHWS | LHCS | LHDS | 01 or more | 32 | 61.5 | 28 | — | 50.5 | 7 | — |
| LHWM | LHCM | LHDM | 60 | 120 | 55 | — | 101 | 14 | — | ||
| LHWL | LHCL | — | 80 | 160 | 74 | — | 134 | 20 | — | ||
| Japanese Landscape Type | LWWS | LWCS | LWDS | 61.5 | 32 | 57.5 | — | 21 | 7 | 30.5 | |
| LWWM | LWCM | LWDM | 120 | 60 | 115 | — | 40 | 15 | 60 | ||
| LWWL | LWCL | LWDL | 160 | 80 | 154 | — | 56 | 19 | 61 | ||
| English | PEW | PEC | PED | 60 | 90 | 56 | 26 | 45 | 15 | — | |
| Chinese | CHW | CHC | CHD | 61.5 | 32 | 57.5 | — | 21 | 7 | 30.5 | |
